Red Automatic Sliding Gate Opener High Speed , Electric Gate Motor

Cirolla Motor Co.,Ltd

Red Automatic Sliding Gate Opener High Speed , Electric Gate Motor

  • 1
  • 2
  • 3

Brand Name : CIROLLA

Model Number : 80ZYT

Certification : CE/CCC/ SGS

Place of Origin : Zhejiang, China

MOQ : 500PCS

Price : Negotiation

Payment Terms : T/T,L/C, Western Union

Supply Ability : 50,000pcs/month

Delivery Time : 25-30days

Packaging Details : Standard,10pcs/carton, weight 1.5kg

Contact Now

Red Automatic Sliding Gate Opener High Speed , Electric Gate Motor

Quick Detail:

Motor type: Brushed Reduction Type: Without Worm gear

Rated Voltage: 12V Rated Power: 180W

Application: Electric Sliding Gate

Description:

As its name implies, a slide gate either slides on wheels from left to right or right to left, not unlike many department store automatic doors.

Slide gate operators are commonly installed at the end of the gate in the closed position but can also be installed by the end of the gate in the open position. In America the most common form of automation is a chain attached across the gate near the bottom and passing through the operator, which shuttles it back and forth. In the end of the gate/open position you do not see the chain or any operating equipment near the gate.

Specifications:

Motor Performance:

Type

Brush

Voltage

12VDC

Power

180W

No load Speed

4200rpm

No load Current

3.0A

On load Speed

3300rpm

On load Current

19.5A

Stall torque

≥655m.Nm

Protection class

IP44

Weight

2.0kg

Outline drawings of motor:

Red Automatic Sliding Gate Opener High Speed , Electric Gate Motor

Applications:

This kind of electric dc motor can be widely used for Electric Sliding Gate Openers

Red Automatic Sliding Gate Opener High Speed , Electric Gate Motor

Competitive Advantage:

Quiet Operation - No need to let the neighborhood know when you come and go!

Safe and Secure - High security rolling code transmitters. Two remotes supplied.

Courtesy light -Comes on automatically when the door is in use. The light will stay on for approximately 3 minutes, then turns off automatically.

Automatic Safety Reverse – Garage Ace sensors when someone or something is in the way, and reverses automatically.

Manual Override - Motor can be easily disengaged in the event of power failure for manual operation of door.

Handy Wall Switch - Door can be operated from switch on interior mounted control box independently of remote transmitter.

Automatic Run Time - If motor is activated while disengaged, the auto run time will turn motor off after 30 seconds

DIY Installation - Step-by-step instructions will guide you through installation. the opener can be installed on the left or right-hand side of the door.
